PARTYCAM V2.0 SETUP NOTES
PARTYCAM SETUP SEQUENCE
LED LITEPAD CONTROLS AND MEMORY
SEQUENCE TO SET UP YOUR PARTYCAM V2
WOOD FRAME VERSIONS
Remove hold down plates on each side with screwdriver
Install ipad then replace hold down plates with screwdriver
Turn on Guest Attract light with the little on off switch connected to the battery compartment. The replacement battery is a CR2032, but as long as you turn it off at the end of the night it will last a very long time
To Open camera release hook latch at top and unscrew/loosen knobs on each side
Fold out camera housing so it is at right angle to front. Then carefully lift up and move bellows lens to front. Place pins in the two holes
Secure the latch on the front screw
Straighten out front lens board and tighen knobs
PartyCam camera is set, reverse process to pack up. Use care when folding the bellows back
Install the light pad to mount
Make the connection between the PartyCam and the lamp with the connector. IMPORTANT When you disconnect these ends DO NOT tug or pull on the wires, only the connector parts!! They are firmly connected and will take a little bit of wiggling to disconnect…
This button will remotely turn the light pad on and off. Make sure the light pad switch is in the on position
Light pad intensity and color temp is controled by knob in back push in to swich between setting of brightness or color temp. Turn to adjust
To have it remember settings, once you have your settins set, push and hold the knob in for at least 20-25 seconds. Then as you turn the lightpad on or off your last setting will be remembered
You’re set! Have Fun
